| 110 |
Fanin detect speed error |
Check whether the fan connection is normal, or replace the fan. |
| 111 |
Fanout detect speed error |
Check whether the fan connection is normal, or replace the fan. |
| 120 |
Fanin speed error (Deviation 2000 +) |
Check whether the fan connection is normal, or replace the fan. |
| 121 |
Fanout speed error (Deviation 2000 +) |
Check whether the fan connection is normal, or replace the fan. |
| 130 |
Fanin speed error (Deviation 3000 +) |
Check whether the fan connection is normal, or replace the fan. |
| 131 |
Fanout speed error (Deviation 3000 +) |
Check whether the fan connection is normal, or replace the fan. |
| 140 |
Fan speed is too high |
Please check the environment temperature. |
| 200 |
Power probing error, no power found |
Determine whether power supply connection is normal; update to the latest. |
| 201 |
Power supply and configuration file mismatch |
Replace the correct power supply. |
| 202 |
Power output voltage error |
Upgrade the latest firmware or check the power supply. |
| 203 |
Power protecting |
Please check the environment temperature. |
| 204 |
Power current protecting |
Please check the environment temperature. |
| 205 |
Power current error |
Inspection of power supply in power grid. |
| 206 |
Power input voltage is low |
Improve power supply conditions and input voltage. |
| 207 |
Power input current protecting |
Improve power supply conditions and input voltage. |
| 208 |
Power supply changes too much |
Replace the power supply. |
| 209 |
The deviation value between the power supply setting voltage and the actual voltage suddenly changes. |
Replace the power supply. |
| 210 |
Power error status |
Check power failure code. |
| 211 |
Power output current deviation is too large |
Replace the power supply. |
| 212 |
Power output voltage margin is insufficient |
Contact after-sales. |
| 213 |
Power input voltage and current do not match |
Replace the power supply. |
| 214 |
Power pin did not change |
Contact after-sales. |
| 215 |
Power vout set error |
Contact after-sales. |
| 216 |
Power remained unchanged for a long time |
Replace the power supply. |
| 217 |
Power set enable error |
Replace the power supply. |
| 218 |
Power input voltage is lower than 230 V for high power mode |
Increase input voltage, replace power supply. |
| 219 |
Power input current is incorrect |
Replace the power supply. |
| 233 |
Power output over temperature protection |
Please check the environment temperature. |
| 234 |
Power output over temperature protection |
Please check the environment temperature. |
| 235 |
Power output over temperature protection |
Please check the environment temperature. |
| 236 |
Overcurrent Protection of Power Output |
Please check the environment temperature, check copper row screw. |
| 237 |
Overcurrent Protection of Power Output |
Please check the environment temperature, check copper row screw. |
| 238 |
Overcurrent Protection of Power Output |
Please check the environment temperature, check copper row screw. |
| 239 |
Overvoltage Protection of Power Output |
Inspection of power supply in power grid. |
| 240 |
Low Voltage Protection for Power Output |
Inspection of power supply in power grid. |
| 241 |
Power output current imbalance |
Replace the power supply. |
| 243 |
Over-temperature Protection for Power Input |
Please check the environment temperature. |
| 244 |
Over-temperature Protection for Power Input |
Please check the environment temperature. |
| 245 |
Over-temperature Protection for Power Input |
Please check the environment temperature. |
| 246 |
Overcurrent Protection for Power Input |
Please check the environment temperature. |
| 247 |
Overcurrent Protection for Power Input |
Please check the environment temperature. |
| 248 |
Overvoltage Protection for Power Input |
Inspection of power supply in power grid. |
| 249 |
Overvoltage Protection for Power Input |
Inspection of power supply in power grid. |
| 250 |
Undervoltage Protection for Power Input |
Inspection of power supply in power grid. |
| 251 |
Undervoltage Protection for Power Input |
Inspection of power supply in power grid. |
| 253 |
Power Fan Error |
Replace the power supply. |
| 254 |
Power Fan Error |
Replace the power supply. |
| 255 |
Protection of over power output |
Please check the environment temperature. |
| 256 |
Protection of over power output |
Please check the environment temperature. |
| 257 |
Input or reverse current protection of power supply |
Turn off power and restart, no effect to replace the power supply. |
| 258 |
Power input three-phase voltage imbalance warning |
Inspection of power supply in power grid. |
| 259 |
Power input three-phase voltage unbalance protection |
Inspection of power supply in power grid. |
| 263 |
Power communication warning |
Check whether the screws of the control board are locked. |
| 264 |
Power communication error |
Check whether the screws of the control board are locked. |
| 267 |
Power watchdog protection |
Contact the technician in time. |
| 268 |
Power output over-current protection |
Check the ambient temperature, check the copper bar. |
| 269 |
Power input over-current protection |
Improve power supply conditions and input voltage. |
| 270 |
Power input over-voltage protection |
Inspection of power supply in power grid. |
| 271 |
Power input under-voltage protection |
Inspection of power supply in power grid. |
| 272 |
Warning of excessive power output of power supply |
Please check the environment temperature. |
| 273 |
Power input power too high warning |
Please check the environment temperature. |
| 274 |
Power fan warning |
Check if the power fan is blocked and may need to be replaced. |
| 275 |
Power over temperature warning |
Please check the environment temperature. |
| 280 |
X- |
|
| 290 |
X |
|
| 300 |
SMX temperature sensor detection error |
Check the connection of the hashboard. |
| 309 |
All temperature sensor detection errors |
Check the connection of the hashboard. |
| 310 |
SMX temperature reading error |
Check whether the control board screw is locked properly, check the connection board and the arrangement contact. |
| 326 |
Liquid cooling temperature sensor communication error |
Replace the power supply. |
| 329 |
Control board temperature sensor communication error |
Replace the power supply. |
| 360 |
The temperature of the hashboard is overheating |
Please check the environment temperature. |
| 370 |
The environment temperature fluctuates too much |
Check the environment temperature. |
| 410 |
SMX detect eeprom error |
Check adapter board and wiring contact. |
| 420 |
SMX parser eeprom error |
Upgrade firmware. |
| 430 |
SMX chip bin type error |
Upgrade firmware. |
| 440 |
SMX eeprom chip num X error |
Upgrade firmware. |
| 450 |
SMX eeprom xfer error |
Check adapter board and wiring contact. Upgrade firmware. |
| 500 |
No software configuration is added for the model |
Upgrade firmware. |
| 510 |
SMX miner type error |
The version and type of hashboard are inconsistent, replace. |
| 520 |
SMX bin type error |
The chip type of the hashboard is inconsistent, replace. |
| 530 |
SMX not found |
Check the connection and arrangement of the adapter board, or replace the control board, check whether the hashboard connector is empty welded. |
| 540 |
SMX reading chip id error |
Check the adapter board and wiring contact, clean the dust on. |
| 550 |
SMX have bad chips |
Contact after-sales. |
| 560 |
SMX loss balance |
Check the hashboard and install again, then screw in the power. |
| 570 |
SMX xfer error chip |
Contact after-sales. |
| 580 |
SMX reset error |
If the hashrate is abnormal, please consult after-sales. |
| 590 |
SMX frequency too low |
Contact after-sales. |
| 600 |
Environment temperature is high |
Please check the environment temperature. |
| 610 |
Temperature warning for high environment |
Check the ambient conditions. |
| 620 |
Liquid cooling liquid temperature protection |
Check liquid temperature. |
| 701 |
Control board no support chip |
Upgrade the corresponding type of firmware. |
| 702 |
Control board version unknown |
Contact after-sales. |
| 710 |
Control board rebooted as exception |
Upgrade the latest firmware. Check whether the control board screw is locked properly. |
| 712 |
Control board rebooted as exception |
Updating the latest firmware. Check whether the control board screw is locked properly. |
| 714 |
The network connection is seriously unstable |
Check the network cable connection or replace the control board. |
| 720 |
SMX serial port communication error |
Upgrade firmware or replace control board. |
| 800 |
Cgminer checksum error |
Re upgrade firmware. |
| 801 |
System-monitor checksum error |
Re upgrade firmware. |
| 802 |
Remote-daemon checksum error |
Re upgrade firmware. |
| 810 |
Liquid cooling error |
Adjust frequency and re-upgrade the liquid cooling firmware. |
| 820 |
Liquid cooling error |
Adjust frequency and re-upgrade the liquid cooling firmware. |
| 901 |
Power rate error |
Check whether the miner has been modified. |
| 902 |
Process exited abnormally |
Upgrade firmware. If it doesn’t work, consult after-sales. |
| 2000 |
No pool information configured |
Check pool configuration. |
| 2010 |
All pools are disabled |
Please check the network or pool configurations. |
| 2020 |
Pool 0 connect failed |
Please check the network or pool configurations. |
| 2021 |
Pool 1 connect failed |
Please check the network or pool configurations. |
| 2022 |
Pool 2 connect failed |
Please check the network or pool configurations. |
| 2030 |
High rejection rate of pool |
Please check the network or pool configurations. |
| 2040 |
The pool does not support asicboost mode |
Check pool configuration. |
| 2050 |
Failed to switch to a new pool |
Please check the network or pool configurations. |
| 2310 |
Hash rate is too low |
Check input voltage, network environment, and ambient temperature. |
| 2320 |
Hash rate is too low |
Check input voltage, network environment, and ambient temperature. |
| 2340 |
The loss of hash rate is too high |
Check input voltage, network environment, and ambient temperature. |
| 2350 |
The loss of hash rate is too high |
Check input voltage, network environment, and ambient temperature. |
| 501 |
SMX chip voltage too low |
Contact after-sales. |
| 502 |
SMX chip voltage change |
Replace the power supply. |
| 503 |
The maximum temperature of the SMX chip is too high |
Check the heat dissipation of the miner. |
| 504 |
The SMX chip temperature exceeds the maximum |
Check the heat dissipation of the miner. |
| 505 |
SMX chip temperature protection |
Please check the environment temperature. |
| 507 |
SMX liquid velocity is abnormal |
Check if the liquid flow is normal. |
| 508 |
SMX chip temperature calibration failed |
Reset. |
| 5090 |
Chip temperature calibration abnormality |
Try to stop the machine for a while and then restart it, or restore factory settings, or check the heat dissipation of the hash board. |
| 511 |
SMX Frequency Up Timeout |
Reboot. |
| 8000 |
WhatsminerTool version is too low |
Download the latest WhatsminerTool. |
| 8010 |
Frequency is not up to standard |
Upgrade the latest software or reset. |
| 8020 |
Hashrate is not up to standard |
Upgrade the latest software or reset. |
| 8400 |
Wrong software version (older or not the official version) |
Upgrade to the correct software version. |
| 8410 |
Wrong software version (M2x mining rig uses M3x firmware, or M3x uses M2x firmware) |
Upgrade to the correct software version. |
| 8700 |
Miner and power supply model do not match |
Replace the correct power supply. |
| 100000 |
Security library error |
Upgrade the latest firmware or burn the card. |
| 100001 |
/antiv/signature Illegal |
Upgrade the latest firmware or burn the card. |
| 100002 |
/antiv/dig/initd.dig Illegal |
Upgrade the latest firmware or burn the card. |
| 100003 |
/antiv/dig/pf_partial.dig Illegal |
Upgrade the latest firmware or burn the card. |
| 100100 |
Security btminer be removed |
Upgrade the latest firmware or burn the card. |
| 110000 |
Security illegal file |
Upgrade the latest firmware or burn the card. |
| 110001 |
Security virus 0001 is removed |
Upgrade the latest firmware or burn the card. |
